The FT232B is a USB to serial UART interface with the following advanced features:

◆ Single Chip USB to Asynchronous Serial Data Transfer
◆ Full Handshaking & Modem Interface Signals
◆ UART I/F Supports 7 / 8 Bit Data, 1 / 2 Stop Bits and Odd/Even/Mark/Space/No Parity
◆ Data rate 300 => 3M Baud (TTL)
◆ Data rate 300 => 1M Baud (RS232)
◆ Data rate 300 => 3M Baud (RS422/RS485)  7. 384 Byte Receive Buffer / 128 Byte Transmit Buffer for high data throughput
◆ Adjustable RX buffer timeout
◆ Fully Assisted Hardware or X-On / X-Off Handshaking In-built support for event characters and line break condition
◆ Auto Transmit Buffer control for RS485
◆ Support for USB Suspend / Resume through SLEEP# and RI# pins
◆ 4.35V to 5.25V single supply operation
◆ Support for high power USB Bus powered devices through PWREN# pin
◆ Integrated level converter on UART and control signals for interfacing to 5V and 3.3V logic
◆ Integrated 3.3V regulator for USB IO
◆ Integrated Power-On-Reset circuit
◆ Integrated 6MHz – 48Mhz clock multiplier PLL
◆ UHCI / OHCI / EHCI host controller compatible
◆ USB 1.1 and USB 2.0 compatible
◆ USB VID, PID, Serial Number and Product Description strings in external EEPROM
◆ EEPROM programmable on-board via USB
◆ Available as a compact lead free RoHS compliant 32-LD LQFP package (FT232BL) or 32-LD QFN package (FT232BQ).

包裝內容

轉接線 x1
